Low Temperature Scanning Probe Microscopy

About

A notable feature of scanning probe microscopy (SPM) is its amenability to instrumental developments that constantly add new application areas to its domain. Amidst this progress, we drive SPM toward becoming a multipurpose tool for the precise manipulation of nanoscale quantum bits on surfaces.

Research Topics

  • Millikelvin STM with magnetic cooling
  • Fabrication of atomic-scale quantum structures
  • Scanning Quantum Dot Microscopy (SQDM)
  • High-resolution SPM with functionalised tips

Contact

Prof. Dr. Ruslan Temirov

PGI-3

Building 02.4w / Room 323

+49 2461/61-3462

E-Mail

Members

Dr. Denis KrylovResearch engineerBuilding 02.4w / Room 129+49 2461/61-3403
Dr. Sven JustPostdocBuilding 02.4w / Room 206+49 2461/61-6525
Stefan SchultePhD studentBuilding 02.18 / Room 2006+49 2461/61-96070
Emilio ScontrinoMaster studentBuilding 02.18 / Room 2006+49 2461/61-96070

Research

a

Millikelvin STM with Magnetic Cooling

We have recently developed an ultra-high vacuum scanning tunnelling microscope that reaches a base temperature of 0.03 Kelvin. It employs adiabatic demagnetisation refrigeration (ADR).

a

Fabrication of Atomic-Scale Quantum Structures

Using SPM for controlled single-molecule and atom manipulation, we search for new ways of fabricating surface structures whose quantum properties can be exploited for fundamental studies of quantum entanglement, possibly leading to future applications in quantum technology.

a

Scanning Quantum Dot Microscopy (SQDM)

Our single-molecule manipulation experiments have led us to the discovery of a new scanning probe technique that is able to image nanoscale variations of the electrostatic potential of surfaces with very high sensitivity and spatial resolution.

a

High-Resolution SPM with Functionalised Tips

We have been the first to resolve the inner structure of a large organic molecule with scanning probe microscopy, providing images that resemble structure formulae of chemistry textbooks. To this end, we used STM tips that were functionalised with molecular hydrogen.

Publication List

Recent publications

  • Taner Esat, Dmitriy Borodin, Jeongmin Oh, Andreas J Heinrich, F Stefan Tautz, Yujeong Bae, Ruslan Temirov; A quantum sensor for atomic-scale electric and magnetic fields. 25 July 2024 Nat. Nanotechnol. https://doi.org/10.1038/s41565-024-01724-z
  • Rustem Bolat, Jose M Guevara, Philipp Leinen, Marvin Knol, Hadi H Arefi, Michael Maiworm, Rolf Findeisen, Ruslan Temirov, Oliver T Hofmann, Reinhard J Maurer, F Stefan Tautz, Christian Wagner; Electrostatic potentials of atomic nanostructures at metal surfaces quantified by scanning quantum dot microscopy. 13 March 2024 Nature Communications volume 15, Article number: 2259 https://doi.org/10.1038/s41467-024-46423-4
  • Taner Esat, Markus Ternes, Ruslan Temirov, F Stefan Tautz; Electron spin secluded inside a bottom-up assembled standing metal-molecule nanostructure. September 2023 Phys. Rev. Research 5, 033200 https://doi.org/10.1103/PhysRevResearch.5.033200
  • Taner Esat, Xiaosheng Yang, Farhad Mustafayev, Helmut Soltner, F Stefan Tautz, Ruslan Temirov; Determining the temperature of a millikelvin scanning tunnelling microscope junction. 21 April 2023 Communications Physics volume 6, Article number: 81 https://doi.org/10.1038/s42005-023-01201-4
  • Jose Martinez-Castro, Rustem Bolat, Qitang Fan, Simon Werner, Hadi H Arefi, Taner Esat, Jörg Sundermeyer, Christian Wagner, J Michael Gottfried, Ruslan Temirov, Markus Ternes, F Stefan Tautz; Disentangling the electronic structure of an adsorbed graphene nanoring by scanning tunneling microscopy. 25 August 2022 Communications Materials volume 3, Article number: 57 https://doi.org/10.1038/s43246-022-00275-x
